• Ensure that bearing's storage location is clean and dry. While removing the package of bearing, shall pay attention to anti-rust and anti-fouling.
• Parts in contact with bearings shall be demagnetized.
• Use multi-row bearing, and shall select bearings with similar outer diameter and inner diameter.
• Use multi-row bearing, and the axial loading of bearing set shall be less than unloading force. Unloading force is related with bearing's loading condition and preload. More details, please contact with TIMG.
• Bearing's spacer shall be made by adopting high level of steel, in order to obtain the hardness of 45~60HRC. The parallelism error of both ends is controlled within 2um.
• Recommended range of preload is 240~860N. Regulation of preload can be done by adjusting the height difference between inner and outer spacers. Detailed proposal can be consulted with TIMG.



● 保证轴承存放位置清洁、干燥。去除包装的轴承应注意防锈和防污，安装前将手清洗干净后涂布一层干净油脂以防污染轴承；
● 与轴承相接触的零件应进行退磁处理；
● 多列组合使用时，选用内外径尺寸公差值相近的轴承；
● 多列组合使用时，轴承组所受轴向负荷小于卸荷力，卸荷力与轴承受载状况及预紧力有关，详情咨询TIMG；
● 轴承隔圈应使用高等级钢材制造以获得45~60HRC的硬度，两端面平行度误差控制在2μm以内；
● 推荐预紧力范围240~860N，预紧力调节可通过调整内外隔圈高度差，具体调整方案请咨询TIMG。
